Hikvision’s HIK-7616NI-I2-16 / DS-7616NI-I2 is a 16 channel network video recorder with 16 embedded plug-and-play PoE ports and 3 TB hard disk storage.

With advanced streaming technology enables smooth live view and data self-correction in poor network conditions with the Hikvision Network Recorder.

Part of Hikvision’s I Series NVR range, it houses a 4-core processor and supports the H.265 intelligent compression standard which aims to reduce bandwidth and storage requirements by up to 50%. This NVR combines features such as audio and video decoding technology which ultimately contribute to the I Series range running smoother than previous generations.

Also featuring 16 PoE network interfaces for easy plug and play setup and capable of 4K ultra HD video output via HDMI and 1080P via VGA, this NVR supports up to 12MP resolution recording.

Model: DS-7616NI-I2-16P-3TB

Features

• 16 plug and play independent PoE interfaces
• 160Mbps throughput
• Up to 12 megapixels resolution recording
• Supports H.265/H.264/H.264+/MPEG4
• HDMI output to 4K (3840×2160 )
• VGA output at up to 1080P resolution
• Up to 8TB capacity for each HDD
• Dual operating systems ensure high reliability
• Video content analytics (VCA)
• Mobile application and PC client
• Simplified remote access setup

Specifications

• Video And Audio
• IP Video Input

  16-ch

  Up to 12 MP resolution

• Incoming Bandwidth160 Mbps
• Outgoing Bandwidth256 Mbps
• HDMI Output4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• VGA Output1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• Video Output ModeHDMI/VGA independent output
• CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
• Audio Output1-ch, RCA (Linear, 1 KΩ)
• Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
