Hikvision Indicator module, DS-KD-IN

Model: DS-KD-IN

Indicator module, module connection with RS-485 , IP65,Backlight.

Surface mounting, 98.21mmx100.21 mm x33.7mm, powered by other module (Power input: 12VDC, Power output: 12VDC)

Indicator Module

• Modular door station Indicator module, needs mouting bracket, IP65, Backlight
• Indicates the device status: Calling, opening door and two-way audio
• Easy to and extend

Specifications

• Installation: Flush mounting, surface mounting
• Indicator: 3
• With package: 326 g

• Without package: 165 g
• Protective Level: IP65
• Power Supply Method: 12 VDC (powered by the other module)
• Working Temperature: -40° C to +55° C(-40° F to 131° F)
• Working Humidity: 10% to 95%
• Dimensions: 98.5 mm × 100 mm × 33.7 mm (3.87" × 3.95" × 1.33")
• Application Environment: Outdoor
• Power Consumption: ≤ 2 W
